U 35 (S185)

New german navy fuel-cell submarine on synchrolift at TKMS yard in Kiel
2012-03-27

ALSTER (A 50)

At Kiel Marinearsenal 2012-03-26
Fleet Service Vessel (OSTE-Class Type 423)
Part of the 1st SUBMARINE SQUADRON
L: 83.50m B: 14.60m D: 4.20m/ 6.27m with sonar
Built: Flensburger Schiffbaugesellschaft, Flensburg
Comm.: 1989/10/05
Displ.: 2,560ts 38 Crew
2 Deutz KHD SBV 16 M 628 3256 kW each 19.20kn

DOCK C (Submarine Pressure Testing Dock)

At Kiel Marinearsenal - recently sold to Turkey -
to be converted to floating dock 2012-03-26



The World's only Submarine Pressure Testing Dock (Class 715)
Showing clearly her entrance
Displ. 13,106tons
L: 93.0m B: 26.50m D: 3.60m
11 Crew Built 1967

HERMELIN (S73) P6123

At Kiel Marinearsenal 2012-03-26

FRETTCHEN (S76) P6126

At Kiel Marinearsenal 2012-03-26

PUMA (S72) P6122

Kieler Förde inbound 2012-03-26

MITTELGRUND (Y 864)

Passing Holtenau eastbound 2012-03-14
German Stollergrund class (Type 745) trials craft/multipurpose
*1989 Elsflether Werft (Comm: 1989/08/23)
Displacement: 450tons full load
Dimensions: 38.6 x 9.20 x 3.20 meters
Propulsion:1 Deutz MWM , 1 shaft, 1,240 kW, 12.0 knots
Crew: 7civilian + 6 trials personnel

Oldenburg (F263) & BRAUNSCWEIG (F260)

At Kiel Marinearsenal 2012-03-08
K130 Braunschweig class is Germany's newest class of ocean-going corvettes.

OLDENBURG (F263)

At Kiel Marinearsenal March 08, 2012
K130 Braunschweig class is Germany's newest class of ocean-going corvettes.
Fourth ship of the class
*2007 Blohm & Voss, Hamburg (TKMS)
Displacement: 1,840 tonnes
Length: 89.12 m Beam: 13.28 m Draft: 3.40 m
2 x MTU 1163 20V Diesel (each 7400 kW) Speed: 26 knots
Armament: 1 Otobreda 76 mm gun, 2 MLG 27 mm autocannons, 2x 21 cell RAM launcher, 2 cell launcher with RBS-15 Mk. 3 surface-to-surface missiles, mine laying capability

BRAUNSCHWEIG (F260)

Kiel-Marine-Arsenal March 08, 2012
German Corvette (Braunschweig Class)
K130 Braunschweig class is Germany's newest class of ocean-going corvettes
Displacement: 1,840 tonnes
Length: 89.12 m Beam: 13.28 m Draft: 3.40 m
2 x MTU 1163 20V Diesel (each 7400 kW) Speed: 26 knots
Armament: 1 Otobreda 76 mm gun, 2 MLG 27 mm autocannons, 2x 21 cell RAM launcher, 2x 2cell launcher with RBS-15 Mk. 3 surface-to-surface missiles, mine laying capability
