Donnerstag, 13. Oktober 2011

OSTE (A 52)

At Kiel Marinearsenal, new antenna fitted  2011-10-12
Type 423 Oste class are purpose built SIGINT/ELINT and reconnaissance ships of the German Navy. Officially designated as fleet service ships, they replaced the Type 422 class. Commissioned July 30, 1988
Built at Flensburger Schiffbau-Gesellschaft in Flensburg. All ships are currently based in Eckernförde and belong to the 1st submarine squadron stationed in Eckernförde.

DSC01940

Mittwoch, 12. Oktober 2011

HAMELN (M 1092)

Kieler Förde inbound, Laboe in background
German Minesweeper Class 352, TROIKA-MOD-Control-Vessel.
* 1990 Kröger Werft (Lürssen Group), Rendsburg
Comm.: 1990/07/17
Length: 54.4m Beam: 9.2m Draft: 2.5m
Displ.: 590ts
Converted from fast minesweeper to drone control vessel

M_1092_KF_1210_001

M_1092_KF_1210_002

M_1092_KF_1210_003

M_1092_KF_1210_004

M_1092_KF_1210_005

M_1092_KF_1210_006

M_1092_KF_1210_007

U 23 (S 172)

Decommissioned (2011-03-31) German Navy Class 206 submarine laid up at Kiel Marinearsenal 2011-10-12

DSC01926

GRÖMITZ (M 1064)

At Kiel Marinearsenal 2011-10-12

DSC01968

SPESSART (A 1442)

Kiel Harry Stallzus Scheerhafen jetty loading fuel
Spessart class (Type 704) fleet oiler
Displacement: 14,260 tons full load
Dimensions: 130.2 x 19.3 x 8.2 meters
Propulsion: 1 diesel, 1 shaft, 8,000 bhp, 16 knots
Crew: 42 civilian
Former commercial tanker built 1974 purchased 1977

DSC02215

SPESSART_A1442_STALLZUS_001

WEILHEIM (M 1059)

Type 332 Frankenthal class mine hunter
inbound to Kiel Tirpitzhafen 2011-10-12

DSC02052

DSC02048

Donnerstag, 15. September 2011

HNoMS THOR HEYERDAHL F314

Newest Norwegian Navy frigate (Fridtjof Nansen-class)
on measurement and demagnetisation trials at WTD 71
in Kiel Friedrichsort towed by two tugs 2011-09-15

THOR_HEYERDAHL_KF1_003

DSC00504-1

DSC01103

DSC01121-1

THOR_HEYERDAHL_KF1_001

THOR_HEYERDAHL_KF1_002

THOR_HEYERDAHL_KF1_005

THOR_HEYERDAHL_KF1_006

FNS Céphée (M652)

French navy minesweeper inbound Kieler Förde for Kiel Canal transit 2011-09-15

DSC00129

DSC00211

BAD RAPPENAU (M1067)

Kieler Förde inbound passing Holtenau 2011-09-15

DSC00336

DSC00340

DSC00362

DSC00379

HOMBURG (M1069) towed by Y812

German Navy minesweeper under tow by tug Y812 (Lütje Hörn) on Kieler Förde 2011-09-15

DSC00172

DSC00206

Montag, 4. Juli 2011

FRANKFURT AM MAIN (A 1412)

Turning in front of Kiel Tirpitzhafen-Tirpitzmole (Navy port) assisted by tugs KIEL and HOLTENAU 2011-07-04

Type 702 Berlin class replenishment ship/task force supplier/combat support ship
*2002 Flensburger Schiffbau-Gesellschaft
Commissioned: May 27, 2002 Homeport: Kiel
L: 173.70m B: 24m D: 7,4m
Displ. 18.637to.
139 (+94) Crew
Propulsion: 2 diesel-engines, 5340 kW each 20.0kn
Armament: 4 MLG 27 mm autocannons, Stinger surface to air missile (MANPADS)
Hangar:2 Sea King or MH90 helicopters
Hospital (Marineeinsatzrettungszentrum) with 45 beds

DSC08452

DSC08490

DSC08512

DSC08536

Freitag, 17. Juni 2011

HNLMS DE RUYTER (F 804)

Arriving Kieler Förde for Kiel Week visit 2011 after participating at Baltops 2011.

HNLMS De Ruyter (F804) is the third De Zeven Provinciën class frigate of the Royal Netherlands Navy. It was laid down in 2000, launched in 2002, and commissioned in 2004. The frigate is named after the famous Dutch admiral Michiel de Ruyter (1607–1676).

Commissioned: 2004-04-24
Class and type: De Zeven Provinciën class frigate
Displacement: 6,050 tonnes (full load)
Length:144.24 m Beam:18.80 m Draft:5.18 m
Propulsion:2 propeller shafts, controllable pitch propellers, 2 Wärtsilä 16V6ST diesel engines, 8.4 MW each, 2 Rolls Royce Spey SM1C gas turbines, 18.5 MW each, 4 GEC Alsthom Paxman diesel-generators, 1650 kW each, Speed:    30 knots
Complement: 174 (227 incl. command staff)

DE_RUYTER_K_001

DE_RUYTER_K_002

HNLMS ZUIDERKRUIS (A832)

Arriving Kieler Förde for Kiel Week 2011 visit after Baltops 2011

HNLMS Zuiderkruis (A832) is one of two replenishment ships serving with the Royal Netherlands Navy. The Zuiderkruis entered service in 1975 and is to be decommissioned at the end of 2011.

Class and type: Auxiliary Replenishment Ship
Displacement: 16,900 tons
Length: 170 m Beam:20 m Speed:21 knots
Complement: 170-190
Armament:1 x Goalkeeper CIWS system, up to 8 12.7 mm machine guns, up to 3 helicopters

ZUIDERKRUIS_001

ZUIDERKRUIS_002

ZUIDERKRUIS_003

ZUIDERKRUIS_004

ZUIDERKRUIS_005

ZUIDERKRUIS_006

ZUIDERKRUIS_K_001

HDMS ABSALON (L16)

HDMS Absalon (L16) and her sister ship HDMS Esbern Snare (L17) are the biggest ships ever to serve in the Royal Danish Navy (RDN), and are the two members of the Absalon-classcommand and support ships. HDMS Absalon is the flagship of the Royal Danish Navy.

Builder: Odense Staalskibsværft Laid down: November 2003 Launched: 30 January 2005  Commissioned: 2007  Homeport: Naval Station Korsør

Class and type: Absalon-class command and support ship
Displacement: 6,300 tonnes
Length: 137.6 m Beam: 19.5 m Draft: 6.3 m
Propulsion: 2 × MTU 8000 M70 diesel engines; two shafts
22,300 bhp (16.4 MW) Speed: >28 knots (52 km/h)
Range: 9,000 nmi (17,000 km) at 15 kn (28 km/h)

ABSOLON_(L16)_K_001

ABSOLON_(L16)_K_003

ABSOLON_(L16)_K_004

ABSOLON_(L16)_K_005

ABSOLON_(L16)_K_006

ABSOLON_(L16)_K_008

ABSOLON_(L16)_K_009

ABSOLON_(L16)_K_010

ABSOLON_(L16)_K_011

ABSOLON_(L16)_K_012
