Freitag, 17. Juni 2011

HNLMS DE RUYTER (F 804)

Arriving Kieler Förde for Kiel Week visit 2011 after participating at Baltops 2011.

HNLMS De Ruyter (F804) is the third De Zeven Provinciën class frigate of the Royal Netherlands Navy. It was laid down in 2000, launched in 2002, and commissioned in 2004. The frigate is named after the famous Dutch admiral Michiel de Ruyter (1607–1676).

Commissioned: 2004-04-24
Class and type: De Zeven Provinciën class frigate
Displacement: 6,050 tonnes (full load)
Length:144.24 m Beam:18.80 m Draft:5.18 m
Propulsion:2 propeller shafts, controllable pitch propellers, 2 Wärtsilä 16V6ST diesel engines, 8.4 MW each, 2 Rolls Royce Spey SM1C gas turbines, 18.5 MW each, 4 GEC Alsthom Paxman diesel-generators, 1650 kW each, Speed:    30 knots
Complement: 174 (227 incl. command staff)

DE_RUYTER_K_001

DE_RUYTER_K_002

HNLMS ZUIDERKRUIS (A832)

Arriving Kieler Förde for Kiel Week 2011 visit after Baltops 2011

HNLMS Zuiderkruis (A832) is one of two replenishment ships serving with the Royal Netherlands Navy. The Zuiderkruis entered service in 1975 and is to be decommissioned at the end of 2011.

Class and type: Auxiliary Replenishment Ship
Displacement: 16,900 tons
Length: 170 m Beam:20 m Speed:21 knots
Complement: 170-190
Armament:1 x Goalkeeper CIWS system, up to 8 12.7 mm machine guns, up to 3 helicopters

ZUIDERKRUIS_001

ZUIDERKRUIS_002

ZUIDERKRUIS_003

ZUIDERKRUIS_004

ZUIDERKRUIS_005

ZUIDERKRUIS_006

ZUIDERKRUIS_K_001

HDMS ABSALON (L16)

HDMS Absalon (L16) and her sister ship HDMS Esbern Snare (L17) are the biggest ships ever to serve in the Royal Danish Navy (RDN), and are the two members of the Absalon-classcommand and support ships. HDMS Absalon is the flagship of the Royal Danish Navy.

Builder: Odense Staalskibsværft Laid down: November 2003 Launched: 30 January 2005  Commissioned: 2007  Homeport: Naval Station Korsør

Class and type: Absalon-class command and support ship
Displacement: 6,300 tonnes
Length: 137.6 m Beam: 19.5 m Draft: 6.3 m
Propulsion: 2 × MTU 8000 M70 diesel engines; two shafts
22,300 bhp (16.4 MW) Speed: >28 knots (52 km/h)
Range: 9,000 nmi (17,000 km) at 15 kn (28 km/h)

ABSOLON_(L16)_K_001

ABSOLON_(L16)_K_003

ABSOLON_(L16)_K_004

ABSOLON_(L16)_K_005

ABSOLON_(L16)_K_006

ABSOLON_(L16)_K_008

ABSOLON_(L16)_K_009

ABSOLON_(L16)_K_010

ABSOLON_(L16)_K_011

ABSOLON_(L16)_K_012

Commandant l'Herminier (F 791)

Massive air pollution on Kieler Förde again - French frigate inbound for Kiel Week visit after Baltops 2011 - 2011-06-17

Type Aviso
Builder: Arsenal de Lorient, Commissioned: 1981-03-07
Length 80,50 m Breadth 10,30 m Draft 5,60 m Air-Draft 26 m
Displacement  1 100t (W)
Propulsion 2 Pielstick 12 PA 6 BTC Speed 22 knots

COMMANDANT_L'HERMINIER_001

COMMANDANT_L'HERMINIER_003

COMMANDANT_L'HERMINIER_004

COMMANDANT_L'HERMINIER_005

COMMANDANT_L'HERMINIER_007

COMMANDANT_L'HERMINIER_009

USS PHILIPPINE SEA (CG-58)

Arriving for Kiel Week visit 2011 after BALTOPS 2011 manouvre

USS Philippine Sea (CG-58) is a Flight II Ticonderoga-class guided missile cruiser on active service in the United States Navy.

Builder: Bath Iron Works  Commissioned: 18 March 1989
Homeport: Mayport, Florida
Displacement: Approx. 9,600 long tons (9,800 t) full load
Length: 173 m Beam: 16.8 meters Draft: 10.2 meters-
Propulsion: 4 × General Electric LM2500 gas turbine engines, 80,000 shaft horsepower (60,000 kW) 2 × controllable-reversible pitch propellers, 2 × rudders
Speed: 32.5 knots
Complement: 33 officers, 27 Chief Petty Officers, and approx. 340 enlisted

PHILIPPINE_SEAS_010

PHILIPPINE_SEAS_011

PHILIPPINE_SEAS_000

PHILIPPINE_SEAS_001

PHILIPPINE_SEAS_005

PHILIPPINE_SEAS_002

PHILIPPINE_SEAS_004

PHILIPPINE_SEAS_006

PHILIPPINE_SEAS_012

PHILIPPINE_SEAS_013

USS MOUNT WHITNEY (LCC 20)

Kieler Förde inbound for Kiel Week 2011 - 2011-06-17

US Blue Ridge Class Command ship / flagship of the United States
Navy's Sixth Fleet.
*1971 Newport News Shipbuilding & Drydock Company
Commissioned: 16 January 1971
Displacement: 18,400 tons full load
Length: 194.00m Beam: 32.90m Draft: 9.06m full load
Propulsion: Two boilers, one geared turbine
Capacity: 930 Complement: 170 officers and enlisted men; and 155 Military Sealift Command civilian sailors
Armament: Two Phalanx CIWS, Two 25 mm Bushmaster cannons, Four .50 cal.machine guns,Mark 36 SRBOC chaff rockets
Aircraft carried: One helicopter, SH-60 Knight

MOUNT_WHITNEY_(LCC20)_002

MOUNT_WHITNEY_(LCC20)_003

MOUNT_WHITNEY_(LCC20)_004

MOUNT_WHITNEY_(LCC20)_005

MOUNT_WHITNEY_(LCC20)_006

MOUNT_WHITNEY_(LCC20)_007

MOUNT_WHITNEY_(LCC20)_013

MOUNT_WHITNEY_(LCC20)_014

MOUNT_WHITNEY_(LCC20)_017

MOUNT_WHITNEY_(LCC20)_019

MOUNT_WHITNEY_(LCC20)_020

MOUNT_WHITNEY_(LCC20)_021

MOUNT_WHITNEY_(LCC20)_022

V8

Small German navy motor launch (Personnel Tender) Kieler Förde 2011-06-17
Marinestützpunktkommando, Kiel
Class 934 built 1987 by Hatecke

V8_001

V8_002

V8_003
